Description
Twin 15" Horn Loaded Passive Subwoofer for Touring and Installation Applications
Product Features
VSX215B
The 8,000-Watt VSX215B is a direct radiating passive twin 15" subwoofer that is ideally suited for a broad range of speech and music sound reinforcement applications in both fixed, portable, and touring audio systems. VSX215B’s superb low frequency reproduction makes it the perfect choice for deployment in clubs, bars, theatres and AV applications.
Stunning Performance
A dual ported bass reflex system, the VSX215B features dual high powered 15" low frequency drivers that provide extended low frequency response down to 40 Hz – for chest-pounding bass. Fast and accurate transient response enables the VSX215B subwoofer to generate massive quantities of tight low end output that is virtually distortion-free.
Versatility
VSX215B Subwoofers can be easily deployed in a multitude of configurations, thanks to the integral M10 rigging points. For touring and portable applications, the enclosures also feature strategically placed carry handles, which are ergonomically integrated into the sides of each cabinet.
Construction and Connectivity
Finished in a hard wearing semi matt black paint, the cabinet is constructed of internally braced plywood and includes a rugged powder coated perforated steel mesh grille. The rear panel connector plate carries Neutrik speakON* NL4 and barrier strip connectors for input and link connections to accommodate additional subwoofer, or satellite full range loudspeakers.
System
| Frequency Response | 48 Hz – 350 Hz, ±3 dB 40 Hz – 450 kHz, -10 dB |
| Recommended Low Pass Crosssover | 90 – 250 Hz, 24 dB/Oct |
| Nominal Dispersion | Half space |
| Power Handling (IEC) | 2000 W continuous, 8000 W peak |
| Sensitivity | 108 dB (1 W @ 1 m) |
| Maximum SPL | 141 dB continuous, 147 dB peak |
| Impedance | 4 O (parallel) 2 x 8 O (discrete) |
| Components | 2 x 15' (381 mm) LF driver |
Enclosure
| Connectors | 2 x Neutrik speakON* NL4 2 x barrier strip terminals |
| Wiring | |
| Parallel | Pins 1+ / 1- input, pins 2+ / 2- link |
| Discrete | Pins 1+ / 1- input (SUB 1), pins 2+ / 2- input (SUB 2) |
| Dimensions H x W x D | 708 x 1052 x 851 mm (27.9 x 41.4 x 33.5') |
| Net weight | 90.2 kg (198.4 lbs) |
| Construction | 18 mm (¾ ') plywood |
| Finish | Semi matt black paint |
| Grille | Powder coated perforated steel |
| Flying Hardware | M10 x 22 points |
