RCF UP-2321 Power Amplifier (70V/ 4 ohm/ Aux Input)

Write a Review
$999.00
SKU:
UP-2321
UPC:
8024530006457
MPN:
8024530006457
Width:
17.40 (in)
Height:
8.60 (in)
Depth:
3.40 (in)
Shipping:
Free Shipping
Current Stock:

With every purchase of $75 or more, use promo code "HOL24" at checkout to receive a free pair of Technical Pro HPS820 Professional Headphones.

Description

RCF UP2321 Overview

The 320W UP 2321 Power Amplifier from RCF is equipped with a Microphone/Line main input via a removable connector, an XLR connector, or an RJ45 port. The amplifier also features an RCA Auxiliary input for music sources such as CD players and tuners. The amplifier output is available for either low impedance speakers or 100-70 constant voltage line. The Class D amplifier features a switching power supply. The UP 2321 is designed for the transmission of announcements and musical programs. It is ideal for use in restaurants, shops, supermarkets, hotels, offices, department stores, industrial systems and similar applications.

320W RMS digital technology power amplifier
Main input on either removable connector or XLR or RJ45
Main input can have priority over the aux input
Main input has a presence control command
Main input has a high-pass filter useful for improving speech intelligibility
Aux input for music sources on RCA type connector
Aux input with volume and tone controls
100 V - 70 V and 4 ohm outputs
Front panel LEDs indicate the device state (ON, PROT), the priority activation (PRIOR) and the signal/peak level (SIG/PK)

In the Box

  • RCF UP 2321 Power Amplifier (320W

RCF UP2321 Specs

Power Output 320 W RMS
Frequency Response 50 Hz to 15 kHz
Connectors 1 x XLR, microphone/line input
1 x RJ45, paging microphone input
2 x RCA, L/R auxiliary input
1 x 4-pin terminal, input command control
Distortion < 0.3%
Signal / Noise Inputs 1-4: > 60 dB
AUX Input: > 80 dB
Crosstalk Inputs 1-4: > 60 dB
AUX Input: > 80 dB
Line Input Sensitivity Mic: -58 dBu
Phantom: -21 dBu
Line: 0 dBu
Aux: -6 to 13 dBu
Input Impedance Mic: 10 kOhms
Phantom: 5 kOhms
Line: 10 kOhms
Aux: 20 kOHms
Tone Frequency Bass: 80 Hz, ±8 dB
Treble: 13 kHz, ±8 dB
Presence Frequency Bands 2.15 kHz, +10 dB
High-Pass Filter 150 Hz
Output Impedance 4 ohms
Output Voltage 70 V (31 ohms) / 100 V (62 ohms)
Operating Voltage 115-230 V, 50/60 Hz
Power Consumption 600 W
Controls Master volume, Treble, Bass, Gain, Presence
Protections Overload, short circuit, thermal
Dimensions 3.4 x 17.4 x 8.6" (88 x 444 x 220 cm)
Weight 12.2 lb (5.5 kg)
