Description
- The JRX212 System features a low-frequency driver with a 2.5" (64mm) diameter edgewound ribbon voice coil which provides more cross-sectional wire area in the voice coil gap, for efficiency and power handling.
- The JBL 2414H-C 1" (25mm) polymer diaphragm compression driver improves high-frequency performance as well as system reliability.
- The advanced network topology crossover design shapes frequency response and delivers coherent summation in the crossover region.
- High-voltage capacitors and inductors with massive cores and heavy gauge wire enable the crossover network to handle high power without saturating.
- Progressive Transition high-frequency waveguide provides optimal coverage control, reduced distortion, and smooth frequency response.
- The rugged, acoustically superior enclosure is constructed from 0.75" (19mm) MDF (Medium Density Fiberboard) using advanced adhesives and mechanical fastener technology for durability and low-frequency performance.
- SonicGuard protects the high-frequency driver from excess power without interrupting the performance.
- Non-resonant, all-steel handles are used.
- An 18-gauge hexagon perforated, steel grille protects components from damage.
- Dual-angle, pole-mount socket allows the speaker to tilt 10° for uniform audience coverage.
- Power Rating: 250 / 1,000 W
- Frequency Range: At -10 dB : 60 Hz to 20 kHz
- Frequency Response: At ±3 dB : 70 Hz to 19 kHz
- Sensitivity: 99 dB SPL (1 W / 1 m) (@1m)
- Nominal Impedance: 8 Ω
- Amplifier Power: 250 to 500 W into 8 Ω
- Maximum SPL: 129 dB
- Nominal: Dispersion: 90 x 50º
- Crossover Frequency: 1.8 kHz
- High Frequency Driver: JBL 2414H-C 1" (25 mm) polymer diaphragm compression driver mounted on Progressive Transition Waveguide
- Low Frequency Driver: JBL M112-8
- Input Connectors
- 1 x Neutrik Speakon NL-4; 0.25" (6.35 mm)
- 1 x TS phone jack; parallel
- Dimensions (H x W x D): 23.0 x 15.7 x 12.8" (584.0 x 399.0 x 325.0 mm)
- Weight: 43.0 lb (19.5 kg)
