Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6

Write a Review
$1,575.00
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
Elation Professional Prisma Wash 25 38X2W 25° lens UV LED IP6
SKU:
PSW325
Width:
5.90 (in)
Height:
11.29 (in)
Depth:
17.50 (in)
Shipping:
Free Shipping
Current Stock:

With every purchase of $75 or more, use promo code "HOL24" at checkout to receive a free pair of Technical Pro HPS820 Professional Headphones.

Please note: if you return the item for any reason, the cost of the headphones will be deducted from your refund amount

Description

PRISMA WASH 25™ is an exterior IP65 rated UV wash luminaire that produces 365nm peak true UV output with zero visible light. Features include an impressive 20 degree narrow beam angle, manual adjustable tilt positioning and versatile rigging options, a user friendly digital 2.5 inch LCD touch screen control panel, intuitive DMX-512 and RDM control.
Optional accessories include a Black Glass diffusion filter to create a complete blackout effect, only allowing UV rays to penetrate, and extended length IP rated power and data linking cables.


Features

IP65 Rated Exterior High-Power UV Wash Luminaire
20 Degree Narrow Beam Angle
365nm Peak True UV Wavelength
Zero Visible Light Output
Optional Black Glass Diffusion Filter


Specifications

SOURCE
(38) 2W High Power UV Diode LEDs
20,000 Hour Average LED Life*

*Test lab conditions. May vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.


PHOTOMETRIC DATA
20 Degree Narrow Beam Angle
365nm True UV Peak Wavelength

EFFECTS
High Speed Electronic Strobe
Variable Dimming Curve Modes

CONSTRUCTION
Rugged IP65 Rated Aluminum Housing
Manual Adjustable Tilt Position

CONTROL
Multiple DMX Channel Modes
Onboard 4 Button Touch Control Panel
DMX-512 and RDM Protocol Support

CONNECTIONS
Locking 5pin XLR Connector In/Out
IP65 Locking Power Connector In
With Wired Digital Communication Network

SIZE / WEIGHT
Length: 17.5” (445mm)
Width: 5.9” (150mm)
Vertical Height: 11.29” (287mm)
Weight: 19 lbs. (8.62 kg)

ELECTRICAL
AC100-240V 50-60Hz
T2A/250V
83W Max Power Consumption

THERMAL
14°F to 113°F (-10°C to 45°C)
Air Cooled

APPROVALS / RATINGS
CE | cETLus | IP65
