Description
Vintage X combines retro amber blinder effects (2000K) with vibrant background RGB LEDs, offering rich multi-color eye candy effects and smooth dimming. With advanced controllability, built-in lightshows, and versatile connectivity, it’s perfect for creative stage and event lighting setups.
Features:
- 4 Foreground Amber LEDs
- 64 Background RGB LEDs
- All LED's are Individually Controllable via DMX
- Built-In Foreground LED Programs
- Built-In Background LED Programs
- Variable White Color Temperature Control (2,700K ~ 10,000K) (RGB LEDs)
- User Selectable LED Refresh Rates (900Hz ~ 25K)
- 6 User Selectable Dim Modes
- 4 User Selectable Dim Curves
- Electronic Strobe (0.1Hz ~ 20Hz)
- Electronic Dimming
Source:
- (4) 60W, 2000K, Amber Foreground LEDs
- (64) 3W RGB Background LEDs
- 50,000 Hour Average Life*
*May vary depending on several factors including but not limited to: Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control, and Dimming.
Optical:
- Amber: 2000K (+/- 50K)
- RGB: 2,700K ~ 10,000K White Color Temperature Range
- Output: 220 Lux, 7000 to 8000 Lumens
- 140° Beam Angle
- 150° Field Angle
Physical:
- IP20, Metal Housing
- Safety Eyelet
- Digital Display
- Coffin Lock System to Interlock up to 8 Vintage X units
- Adjustable Hanging Bracket
- Omega Clamp Receivers (Omega Clamp Sold Separately
Control:
- DMX512
- Aria X2 Wireless Management / DMX System
- Bluetooth
- RDM and RDM Net Compatible
- (9) DMX Channel Modes (8, 13, 22, 39, 43, 196, 200, 208 & 211 Channel modes)
- On-board Manual Control Mode
- Primary / Secondary Mode
Connections:
- 5-pin XLR DMX In/Out Sockets
- IP65 Locking Power In & Thru Sockets
Dimensions & Weight:
- Length: 15.69" (398.4mm) Width: 15.69" (398.4mm) Height: 7.64" (194mm)
- Weight: 18 lbs. (8.2 kg)
Power:
- AC100-240V/50Hz-60Hz Input
- 200W Power Consumption
- Link 2 pieces @120VAC or 4 pieces @ 230VAC
Thermal:
- Ambient Operational Temperature: -4°F to 113°F (-20°C to 45°C)
- Storage Temperature: -22°F to 113°F (-30°C to 45°C)
Certifications & IP Rating:
- CE (Pending)
- cETLus (Pending)
- FCC (Pending)
- IP20
Included Accessories:
(1) IP65 Locking Power Cable
Optional Accessories:
Omega Clamp (107mm)
